The anti-gravity gravity machine. Introducing the ONE.2, an all-new 29er downhill/freeride bike from the fun junkies at Canfield. Built around 29-inch wheels and the patented Canfield Balance Formula™ suspension platform, the ONE.2 is a DH weapon engineered to take on the roughest race tracks and biggest bike-park lines with confidence. And thanks to the ultra-efficient CBF™ tuned linkage, it pedals like nothing with 8 inches of travel should to ensure nothing is wasted, whether you’re sprinting across the finish line or into the next jump.
Channeling the pedigree of the original Canfield The One, the ONE.2 is designed to be as versatile as it is capable. By default, it’s a 29-inch downhill bike with 203 millimeters of travel. But if big hits are your priority and you don’t have access to chairlifts and shuttles, it can be set up to earn its turns. Rear travel can be reduced to 190 millimeters by short-stroking the shock. Pair it with a 180-millimeter fork and a dropper post, and you’ve got a pedal-able freeride machine that’s part monster truck, part billy goat.
Wagon wheels not your thing? The ONE.2 is designed to be run with 27.5 wheels as well. Mullet bike? The ONE.2 has no problem mixing business in the front with a party in the back.
A slack 63-degree head-angle and generous reach across all sizes make it easy to find the sweet spot in the attack position, and 17.3-inch chainstays strike a balance between stability and agility. Premium Öhlins suspension complements the ride qualities of CBF™. Details like internal cable routing featuring machined interchangeable ports to accommodate different cable configurations and a custom CBF™ chainstay protector tie it all together.
The 2020 Canfield ONE.2 is available in Bentonite Grey with orange links, or Avalanche White with black links.
FEATURES
• 29” / 27.5” Downhill/Freeride
• 7005 aluminum with CNC links
• Patented Canfield Balance Formula™ Suspension
• 203mm/190mm travel
• Internal Cable Routing w/ Interchangeable Ports
• Custom CBF Chainstay Protector
• 1.5 headtube
• 20mm pivot bearings
• Replaceable rear derailleur hanger, spare hanger included
• Available in Bentonite Grey with orange links, or Avalanche White with black links
• Available in three sizes
BUILD SPECS
Rear Shock
• DVO Jade Coil
• EXT Arma V3
• EXT Storia Lok V3
• Frames include interchangeable cable ports, removable ISCG05 tabs, two rear derailleur hangers, rear axle and custom chainstay protector. Headsets and seat clamps not included. Headsets are available here. Seat clamps are available here.
FRAME SPECS
• Shock Specs: Metric: 250mm x 75mm (203mm), 250 x 70mm (190mm) (20mmX8mm/40mmX8mm hardware)
• Recommend fork length: 180mm – 200mm
• Headset: 49.6mm upper/lower
• Front derailleur: Not available
• Max. chainring size: 34t (36t w/ driveside spacer)
• Bottom bracket: 83mm, threaded
• Seatpost: 30.9mm, stealth dropper compatible
• Seatpost clamp: 35mm
• Rear dropouts: 150mm x 12mm, Canfield axle included
• 20mm pivot bearings
• ISCG 05
• Brake mount: IS 160mm
• Maximum seatpost insertion: 220mm(S1), 230mm(S2), 240mm(S3)
GEOMETRY
Size |
Size 1 |
Size 2 |
Size 3 |
Top Tube Length (Effective) |
572mm |
600mm |
629mm |
Reach |
425mm |
450mm |
475mm |
Stack |
620mm |
629mm |
638mm |
Standover Height |
681mm |
689mm |
698mm |
Seat Tube Length |
405mm |
415mm |
425mm |
Wheel Base |
1231mm |
1260.5mm |
1290mm |
Head Tube Angle* |
63° |
63° |
63° |
Seat Tube Angle (Effective) |
76° |
76° |
76° |
Seat Tube Angle (Actual) |
67.8° |
67.8° |
67.8° |
Chainstay Length |
440mm |
440mm |
440mm |
Bottom Bracket Drop |
22mm |
22mm |
22mm |
Bottom Bracket Height (Approximate)** |
356.5mm |
356.5mm |
356.5mm |
Head Tube length |
105mm |
115mmm |
125mm |
Geo based on 29” wheels and 601mm axle-to-crown fork
*Öhlins DH fork has 620mm axle-to-crown w/ 62.2 HA
*180/190mm fork w/ 592mm axle-to-crown results in 63.5 HA
**(27.5" wheels result in 337.8mm bb height)
SIZE
|
S1
|
S2
|
S3
|
RIDER HEIGHT
|
5'2"-5'9"
|
5'7"-6'2"
|
5'10"-6'4"
|
ÖHLINS TTX22 SPRING RATE CALCULATOR
Rider Weight (lbs) | Coil Spring Rate (in./lbs) |
120-130 | 297 |
130-140 | 320 |
140-150 | 343 |
150-160 | 365 |
160-170 | 388 |
170-180 | 411 |
180-190 | 434 |
190-200 | 457 |
200-210 | 480 |
210-220 | 502 |
220-230 | 525 |
230-240 | 548 |
240-250 | 571 |
*Please indicate rider weight (geared up) and/or preferred spring rate in order notes on cart page. Recommendations based on 30% sag. Optimal spring rate depends on rider preference, terrain and riding style.
Photos of bike/spec may vary slightly from actual spec based upon pre-production frame and availability of parts. Any substituted parts will be of equal or greater value than original option listed. Complete bikes ship as a frame and build kit. While frames are prepped, reamed, chased and faced, they do require experienced assembly. If you are not confident in fully assembling and tuning your new Canfield bike, we recommend visiting your favorite local bike shop.
Please note that shipping rates for frames will include insurance, but our default shipping rates for complete bikes does not include insurance. Please email us if you would like to add insurance to your complete bike build (typically $35-$45).
