29" WHEELS // HARDTAIL // 130MM FRONT
We say Yelli, you say Screamy. The first hardtail to bring the party to wagon wheels is back with a vengeance. Slice and dice singletrack. Rail pump tracks and jump lines. Load it with frame bags and get lost. Keep up with your spandex-clad friends on the climbs and embarrass them on the descents.
Do whatever you want on the Yelli Screamy, just don’t tell it that it’s a short-travel 29er hardtail.
Complete builds may take seven to 10 days to ship depending on in-stock inventory and parts availability.
BUILD SPECS
|
CORE |
PRO |
|
|
Fork |
Cane Creek Helm 130mm |
RockShox Pike Ultimate 130mm |
|
Cranks |
Canfield AM |
Canfield AM |
|
Chainring |
AbsoluteBlack 32t Round |
AbsoluteBlack 32t Round |
|
Shifter |
SRAM GX Eagle | SRAM X01 Eagle |
|
Derailleur |
SRAM GX Eagle | SRAM X01 Eagle |
|
Cassette |
e*thirteen Helix-R 9-50t | SRAM X01 Eagle 10-52t |
|
Brakes |
TRP Slate T4 | TRP Trail EVO |
|
Rotors |
TRP 180/160mm | TRP 180/160mm |
|
Wheels |
E.Thirteen | Atomik AL30 |
|
Tires |
Maxxis Minion DHF 2.5 / Maxxis Dissector 2.4 |
Maxxis Minion DHF 2.5 / Maxxis Dissector 2.4 |
|
Seatpost |
SDG Tellis | SDG Tellis |
|
Saddles |
Canfield SDG | Canfield SDG |
|
Bar |
e*thirteen 800mm | e*thirteen 800mm |
|
Stem |
Canfield Special Blend 40mm | Canfield Special Blend 40mm |
| Grips | Lizard Skins Charger Evo | Lizard Skins Charger Evo |
|
Seat Clamp |
Canfield | Canfield |
FRAME FEATURES
- 29” Trail/AM Hardtail
- 6061-series aluminum
- Tapered Headtube (44x56)
- Recommended fork length: 120mm - 140mm
- Stealth dropper routing
- ISCG 05 tabs
- 73mm BSA Threaded BB
- Crank Length: 155mm (SM), 160mm (MD), 165mm (LG), 170mm (XL)
- 30.9mm seat post (34.9/35mm clamp compatible)
- Boost Spacing
- Rear Tire Clearance: 80mm/3.15 inches between stays (plus tires not recommended on 29-inch wheels due seat-tube clearance)
- Brake mount: PM 160mm
- Three water-bottle mounts
- Includes derailleur hanger, rear axle and hardware
GEO & SIZING
|
|
SMALL |
MEDIUM |
LARGE |
XL |
|
Top Tube Length (Effective) |
571 |
597 |
624 |
650 |
|
Reach |
425 |
450 |
475 |
500 |
|
Front Center |
736 |
763 |
793 |
820 |
|
Stack |
630 |
635 |
644 |
649 |
|
Standover |
677 |
709 |
746 |
769 |
|
Wheel Base |
1,154 |
1,181 |
1,210 |
1,237 |
|
Head Tube Angle* |
65.5 |
65.5 |
65.5 |
65.5 |
|
Head Tube Length |
105 |
110 |
120 |
125 |
|
Seat Tube Angle (Effective) |
77 |
77 |
77 |
77 |
|
Seat Tube Angle (Actual) |
76.4 |
76.4 |
76.4 |
76.4 |
|
Seat Tube Length |
380 |
420 |
460 |
490 |
| Max. Seatpost Insertion | 280 | 320 | 360 | 390 |
|
Chainstay Length |
424 |
424 |
424 |
424 |
|
Bottom Bracket Height |
316.5 |
316.5 |
316.5 |
316.5 |
|
Bottom Bracket Drop |
58 |
58 |
58 |
58 |
|
Rider Height*** |
5'2"-5'7" |
5'5"-5'11" |
5'9"-6'3" |
6'1"-6'6" |
*Geo based on 541mm axle to crown fork, 130mm travel
***Recommendation only. Sizing depends on body type, personal preference and riding style.
