Regular price
$5,999.99
Sale price
$4,499.99
Unit price
per

Learn more about payment and financing options

Shipping calculated at checkout.

29" Wheels // 138mm Rear // 140/150mm Front

There’s a party on the trails, and you’re invited. The Tilt is an efficient all-rounder that climbs like a mountain goat with a meth habit. But make no mistake—like any bike with a skull on the headtube, it’s ready to party when gravity takes over.

** NEW BUILD SPECS + BIKE OF THE YEAR SALE PRICING **

TILT COMPONENT OPTIONS
Fork Cane Creek Helm MK II 140m
Fox 36 SL FACTORY GRIP X 140
RockShox Pike Ultimate C2 140mm
Shock Cane Creek Double Barrel Kitsuma Air
Fox Float X Factory Air
RockShox Super Deluxe Air
Drivetrain SRAM GX Shifter, Derailleur, e13 Helix-R 9-50t Cassette
SRAM X01 Eagle Shifter, Derailleur, 10-52t Cassette
Shimano XT Shifter, Derailleur, e13 Helix-R 9-50t Cassette
Cranks Canfield All Mountain Cranks (165mm length)
Chainring e*thirteen 32t Round
Brakeset TRP Slate T4 w/180mm Rotors
Wheels e*thirteen LG1+ Enduro
Tires Maxxis DHF 2.5 & Maxxis Dissector 2.4
Seatpost SDG Tellis
Saddle SDG Canfield Limited Edition
Handlebar e*thirteen Base 800mm
Stem e*thirteen Base Stem
Seat Clamp Canfield Black Forged

Complete builds may take 7-10 days to ship depending on in-stock inventory and parts availability.



GEO & SIZING Small Medium Large XL
Top Tube Length (Effective) 566mm 593mm 620mm 646mm
Reach 425mm 450mm 475mm 500mm
Front Center 746mm 773mm 800mm 827mm
Stack 615mm 620mm 624mm 629mm
Standover 697mm 730mm 762mm 779mm
Wheel Base 1,170mm 1,198mm 1,225mm 1,252mm
Head Tube Angle* 65° 65° 65° 65°
Head Tube Length 110mm 115mm 120mm 125mm
Seat Tube Angle (Effective) 77° 77° 77° 77°
Seat Tube Angle (Actual) 69.2° 69.2° 69.2° 69.2°
Seat Tube Length 380mm 420mm 460mm 490mm
Chainstay Length 425mm 425mm 425mm 425mm
Bottom Bracket Height (Approx.) 343mm 343mm 343mm 343mm
Bottom Bracket Drop 32mm 32mm 32mm 32mm
Rider Height 5'2"-5'7" 5'5"-5'11" 5'9"-6'3" 6'1"-6'6"

*Geo based on 552mm axle-to-crown fork with 140mm travel.
**Based on 2.5 tires and 552mm axle-to-crown fork.
***Recommendation only. Sizing depends on body type, personal preference, and riding style.

Seat Height vs. Effective Seat Tube Angle
600mm = 77.5 °
700mm = 76.3 °
800mm = 75.4 °

FEATURES
• 29” Trail/All-Mountain
• Patented Canfield Balance Formula™ Suspension
• Internal cable routing
• Forged clamshell bottom bracket assembly
• Redesigned rear-triangle with forged one-piece vertical stays
• One-piece upper and lower links
• Custom CBF Chainstay Protector
• Water-bottle mount
• Replaceable rear derailleur hanger

FRAME SPECS
• 7005 aluminum with 7075 T6 CNC links
• Internal cable routing with interchangeable machined ports
• Shock Specs (Metric):
     -138mm travel 210mm x 55mm (20mmX8mm/40mmX8mm hardware)
• Recommend fork length: 130mm – 150mm
• Tapered Headtube 44mm upper/56mm lower
• Recommended fork offset: 44mm
• 15mm pivot bearings (6902 Max)
• Seatpost: 30.9mm, stealth dropper compatible
• Seatpost clamp: 35mm
• Rear dropouts: Boost 148mm x 12mm, Canfield axle included
• Max rear tire size: 29x2.5/27.5x2.8
• Removable ISCG tabs: ISCG 05
• Brake mount: Post Mount 180mm
• Bottom bracket: 73mm threaded
• Crank Length: 160mm (SM), 160mm (MD), 165mm (LG), 165mm (XL)
• Seatpost max insertion: 250mm(S), 265mm(M), 305mm(L), 340mm(XL)
• Weights (medium):
     -Frame w/ hardware: 7.6 pounds
     -Frame w/ shock: 8.9 pounds
     -Complete (carbon wheels, air shock/fork): 31.8 pounds

NOTE: Full assembly is required on complete bikes. Photos for illustration purposes only. Actual component spec not shown.
