NIMBLE 9 - Frame + Fork
NIMBLE 9 - Frame + Fork
NIMBLE 9 - Frame + Fork
NIMBLE 9 - Frame + Fork
NIMBLE 9 - Frame + Fork
NIMBLE 9 - Frame + Fork
NIMBLE 9 - Frame + Fork
NIMBLE 9 - Frame + Fork
NIMBLE 9 - Frame + Fork

NIMBLE 9 - Frame + Fork

Regular price
$2,099.99
Sale price
$1,599.99
Unit price
per

Learn more about payment and financing options

Shipping calculated at checkout.

ORDER NOW FOR MID-JULY 2024 DELIVERY

29" WHEELS // HARDTAIL // 150MM FRONT

The original hardcore hardtail. Handcrafted in small batches, the Canfield Bikes Nimble 9 is a steel hardtail built to get rowdy. Combining the revered ride quality of 4130 chromoly steel with aggressive all-mountain geometry, the Nimble 9 challenges preconceptions of mountain bikes with both big wheels and rigid rear-ends.

*Photos are for illustration purposes. Final production details and build spec subject to change. Full assembly required.


FRAME FEATURES

  • 29″ All Mountain
  • 4130 chromoly steel
  • Radial-bent seat stays for vertical compliance
  • Increased reach and shorter seat tube
  • 66° head angle (w/ 150mm fork)
  • Recommended fork length: 140mm - 160mm
  • Custom sliding Boost 148mm x 12mm rear dropouts, axle included
  • 73mm BSA Threaded BB
  • 30.9mm seat post
  • 34.9 or 35mm clamp size
  • Adjustable 16.33“ – 16.93” chainstays
  • Brake mount: IS 160mm
  • Singlespeed-able
  • Stealth cable routing
  • Two water bottle bosses
  • Includes dropouts/derailleur hanger, rear axle and hardware
  • Max. chainring size: 34t round / 32t oval
  • Max. seatpost insertion: 200mm(S), 235(M), 275(L), 320(XL)

Full assembly is required on complete bikes.

Canfield Nimble 9 Geo
(
Based on 150mm fork, 563mm Axle to Crown)

Size S M L XL

Top Tube Length (Effective)*

570mm

597mm

625mm

652mm

Reach

425mm

450mm

475mm

500mm

Stack*

634mm

638mm

648mm

656mm

Standover Height*

745mm

780mm

800mm

830mm

Seat Tube Length

370mm

405mm

445mm

490mm

Wheel Base*

1156mm

1183mm

1212mm

1241mm

Head Tube Angle

66°

66°

66°

66°

Seat Tube Angle (Effective)

77°

77°

77°

77°

Chainstay Length

415-430mm

415-430mm

415-430mm

415-430mm

Bottom Bracket Height 325mm 325mm 325mm 325mm

Bottom Bracket Drop

50mm

50mm

50mm

50mm

Head Tube length

100mm

105mm

115mm

125mm

*Geo based on 150mm travel fork. Static measurement (not sagged).

SIZING
SIZE
S
M
L
XL
RIDER HEIGHT
5'2"-5'7"
5'5"-5'11"
5'9"-6'3"
6'1"-6'6"
*This size chart is only a suggestion. Every riding style and body is different.

*Photos are for illustration purposes. Final production details may vary.
