29"+27.5" MULLET // 169MM REAR // 170MM FRONT
Pedal. Send. Repeat. The Balance is our idea of what an all-mountain bike should be: just as capable of flagrant disregard for line choice and taking big hits in stride as it is of getting you to the top under your own power. Burly enough for bell-to-bell bike-park laps, efficient enough to earn its turns.
>> OUTERBIKE SPECIAL >> SAVE $2500 ON THIS DEMO BIKE
BUILD SPECS
Fork |
RockShox Zeb ULT 170mm 29er |
Shock |
RockShox Select 230 x 65 |
Cranks |
Canfield AM 165mm |
Chainring |
SRAM 32t Round |
Shifter |
SRAM XO1 |
Derailleur |
SRAM XO1 |
Cassette |
SRAM XO1 |
Brakes |
Magura MT7 HC3 |
Rotors |
Magura 180/180mm |
Wheels |
e*thirteen Mullet Wheelset |
Tires |
Maxxis Minion DHF 2.5 |
Seatpost |
SDG Tellis 170mm |
Saddle |
Canfield SDG |
Bar |
e*thirteen Base |
Stem |
Canfield Special Blend |
Seatclamp |
Canfield |
This is a new demo frame and wheels with lightly used components and is in great condition. It will be professionally cleaned and tuned prior to sale (please allow a few extra days for shipping). Used bikes are sold as is but are covered by our two-year factory warranty. All used bike sales are final.
- 29" F / 27.5” R All-Mountain / Enduro Mullet
-
7005 aluminum with CNC links
- Patented Canfield Balance Formula™ Suspension
-
Custom Chainstay Protector
-
Internal Cable Routing
- Tapered headtube
-
15mm pivot bearings (6902 Max)
-
Water-bottle mount
-
Replaceable rear derailleur hanger
- Available in Small, Medium, Large and X-Large
FRAME SPECS
-
Shock Specs: Metric:
- 169mm travel: 230mm x 65mm (22mmX8mm/36mmX8mm hardware)
-
Recommend fork length: 170mm (160mm – 180mm acceptable range)
-
Headset: Tapered 44mm upper/56mm lower
-
Bottom bracket: 73mm BSA threaded
-
Seatpost: 30.9mm, stealth dropper compatible
-
Seatpost clamp: 35mm
-
Rear dropouts: Boost 148mm x 12mm, Canfield axle included
-
Rear tire clearance: 70mm/2.76 inches between stays
-
ISCG tabs: ISCG 05
-
Brake mount: Post 180mm
- Seatpost max insertion: 205mm(S), 225mm(M), 260mm(L), 305mm(XL)
Size |
Small |
Medium |
Large |
XLarge |
---|---|---|---|---|
Top Tube Length (Effective) |
592mm |
613mm |
635mm |
658mm |
Reach |
438mm |
457mm |
476mm |
496mm |
Stack |
606mm |
611mm |
620mm |
629mm |
Standover Height |
697mm |
725mm |
743mm |
762mm |
Seat Tube Length |
380mm |
410mm |
450mm |
490mm |
Wheel Base |
1190mm |
1216mm |
1241mm |
1265mm |
Head Tube Angle |
64° |
64° |
64° |
64° |
Seat Tube Angle (Effective) |
75.7° |
75.7° |
75.7° |
75.5° |
Seat Tube Angle (Actual) |
70.3° |
70.3° |
70.3° |
70.3° |
Chainstay Length |
420mm |
420mm |
420mm |
420mm |
Bottom Bracket Drop |
12.4mm |
12.4mm |
12.4mm |
12.4mm |
Bottom Bracket Height (*Approximate) |
343mm |
343mm |
343mm |
343mm |
Head Tube length |
115mm |
120mmm |
130mm |
140mm |
SIZE
|
S |
M
|
L
|
XL
|
RIDER HEIGHT
|
5'2"-5'7"
|
5'5"-5'11"
|
5'9"-6'3"
|
6'1"-6'6"
|
