29" WHEELS // 163mm REAR // 170mm FRONT
Meet the new maniac on the mountain. Designed to destroy big descents with reckless abandon, unafraid of the effort required to earn them. From enduro stages to bike park laps and backcountry adventures, the Lithium is a big-wheeled warrior ready for anything the mountain throws your way.
Complete builds may take seven to 10 days to ship depending on in-stock inventory and parts availability.
BUILD SPECS
|
BASE |
CORE |
PRO |
|
|
Fork |
MRP Ribbon Air 170mm |
RockShox Zeb Ultimate RC3 170mm |
Fox 38 Factory 170mm |
|
Shock |
Cane Creek DB Kitsuma Air |
Öhlins TTX2 Air |
2024 Fox FLOAT X2 Factory |
|
Cranks |
Canfield AM |
Canfield AM |
Canfield AM |
|
Chainring |
e*thirteen 32t Round |
e*thirteen 32t Round |
e*thirteen 32t Round |
|
Shifter |
TRP | Sram GX | Sram XO1 |
|
Derailleur |
TRP | Sram GX | Sram XO1 |
|
Cassette |
e*thirteen 9-50t | e*thirteen 9-50t | Sram XO1 10-52t |
|
Brakes |
TRP Slate T4 | TRP Slate T4 | TRP Trail Evo |
|
Rotors |
TRP 180mm | TRP 203/180mm | TRP 203/180mm |
|
Wheels |
E.Thirteen | E.Thirteen | Atomik AL 30 |
|
Tires |
Maxxis DHF 2.5 Maxxis Dissector 2.4 |
Maxxis DHF 2.5 Maxxis Dissector 2.4 |
Maxxis DHF 2.5 Maxxis Dissector 2.4 |
|
Seatpost |
SDG Tellis | SDG Tellis | SDG Tellis |
|
Saddle |
Canfield SDG | Canfield SDG | Canfield SDG |
|
Bar |
E.Thirteen Base 800mm | E.Thirteen Base 800mm | E.Thirteen Base 800mm |
|
Stem |
Canfield | Canfield | Canfield |
|
Seatclamp |
Canfield | Canfield | Canfield |
|
|
SMALL |
MEDIUM |
LARGE |
XL |
|
Top Tube Length (Effective) |
575 |
601 |
628 |
655 |
|
Reach |
425 |
450 |
475 |
500 |
|
Front Center |
764 |
791 |
818 |
845 |
|
Stack |
635 |
640 |
644 |
649 |
|
Standover |
702 |
739 |
770 |
782 |
|
Wheel Base |
1193 |
1221 |
1248 |
1275 |
|
Head Tube Angle* |
64.5° |
64.5° |
64.5° |
64.5° |
|
Head Tube Length |
110 |
115 |
120 |
125 |
|
Seat Tube Angle (Effective) |
76.7° |
76.7° |
76.7° |
76.7° |
|
Seat Tube Angle (Actual) |
69.1° |
69.1° |
69.1° |
69.1° |
|
Seat Tube Length |
380 |
420 |
460 |
490 |
|
Chainstay Length |
430 |
430 |
430 |
430 |
|
Bottom Bracket Height (Approx.)** |
350 |
350 |
350 |
350 |
|
Bottom Bracket Drop |
28 |
28 |
28 |
28 |
|
Rider Height*** |
5'2" - 5'7" |
5'5"-5'11" |
5'9"-6'3" |
6'1"-6'6" |
FEATURES
• 29” All-Mountain/Enduro
• Patented Canfield Balance Formula™ Suspension
• Internal cable routing
• Forged clamshell bottom bracket assembly
• Redesigned rear-triangle with forged one-piece vertical stays
• One-piece upper and lower links
• Custom CBF Chainstay Protector
• Water-bottle mount
• Replaceable rear derailleur hanger
• Available in Small, Medium, Large and X-Large
FRAME SPECS
• 7005 aluminum with CNC 7075 links
• Internal cable routing with interchangeable machined ports
• Shock Specs (Metric):
-163mm travel: 230mm x 65mm, (20mmX8mm/40mmX8mm hardware)
• Optimized for air or coil shocks
• Recommend fork length: 160mm – 180mm
• Recommended fork offset: 44mm
• Tapered Headtube 44mm upper/56mm lower
• 15mm pivot bearings (6902 Max)
• Bottom bracket: 73mm, BSA threaded
• Crank Length: 155mm (SM), 160mm (MD), 165mm (LG), 170mm (XL)
• Seatpost: 30.9mm, stealth dropper compatible
• Seatpost clamp: 35mm
• Rear dropouts: Boost 148mm x 12mm, Canfield axle included
• Max rear tire size: 29x2.5/27.5x2.8
• Removable ISCG tabs: ISCG 05
• Brake mount: Post Mount 180
• Seatpost max insertion: 250mm(S), 265mm(M), 305mm(L), 340mm(XL)
• Weights (medium):
-Frame w/ hardware: 7.7 pounds
-Frame w/ shock: 8.8 pounds
-Complete (carbon wheels, air shock): 31.8 pounds
-Complete (aluminum wheels, coil shock): 33 pounds
NOTE: Full assembly is required on complete bikes. Photos for illustration purposes only. Actual component spec not shown.
| Rider Weight | Coil Spring Rate |
| 120-140lbs | 300 |
| 140-160lbs | 350 |
| 160-180lbs | 400 |
| 180-200lbs | 450 |
| 200-220lbs | 500 |
| 220lbs+ |
550 |
|
Shock |
Small |
Medium |
|
Rockshox Super Deluxe Air 2022 (B2) |
NO | YES (Reversed) |
|
Rockshox Super Deluxe Air 2023+ (C1) |
NO | NO |
| Rockshox Super Deluxe Coil 2022 (A1) | YES | YES |
| Rockshox Super Deluxe coil 2023+ (B1) | YES | YES |
|
MRP Hazard Coil |
YES | YES |
|
Cane Creek Kitsuma Air |
YES | YES |
|
Ohlins TTX2 Air |
YES | YES |
|
DVO Topaz |
YES | YES |
|
DVO Jade |
YES | YES |
|
Fox FLOAT X |
NO | YES (Reversed) |
| Fox FLOAT X2 | YES | YES |
|
Fox DHX2 |
YES | YES |
